FireFinder PLUS is an Intelligent Analogue Addressable Fire Alarm Control Panel that is available in 1 to 8 loop panel options.
The FireFinder PLUS Fire Alarm Control Panel is suitable for small to large-sized fire detection systems and is compatible with XP95 and Discovery Detectors.
Powerful and flexible programming is achieved via Ampac’s configuration tool ConfigManager PLUS which includes many pre-engineered programming functions. Simple system programming is easily achieved via the front panel.
FireFinder PLUS is also configurable as a peer-to-peer network with up to 99 panels/nodes with a maximum of 250 Loops.
Check out where FireFinder PLUS has been successfully installed: Completed Projects | Ampac
Approvals: AS 7240-2, AS 7240-4 & AS 4428-3:2010
| Number of Detection Loops | 1-8 Fully Expandable |
| Detection Protocol | Apollo XP95 and Discovery |
| Devices per Loop | 126 |
| Number of Zones | 1999 Programmable Zones |
| Outputs (Programmable) | 4 x 24VDC @ 1A Max, 10K EOL |
| Relay Outputs (Programmable) | 5 x Voltage Free- 24VDC@1A |
| Power Supply | 5A, 14A or 22A |
| Dimensions | |
| SP1X | H 500mm x W 405mm x D 150mm |
| SP8X | H 845mm x W 518.5mm x D 173mm |
| SP16X | H 1200mm x W 625mm x D 240mm |
| SP1X Battery Cabinet | H 300mm x W 405mm x D 150mm |
| SP8X Battery Cabinet | H 420mm x W 518.5mm x D 173mm |
| IP Rating | IP 30 (Indoor Use Only) |
| Panels | |
| 8651-0110 | FireFinder Plus 1 Loop 5A SP1X |
| 8651-0113 | FireFinder Plus 1 Loop 5A SP8X |
| 8651-0116 | FireFinder Plus 1 Loop 14A SP16 |
| 8651-0117 | FireFinder Plus 1 Loop 14A 10U |
| 8651-0118 | FireFinder Plus 1 Loop 14A 16U |
| 8651-0119 | FireFinder Plus 1 Loop 22A 29U |
| Panel Extras | |
| 4210-0042 | SP1X Cabinet Flush Surround |
| 4210-0044 | SP8X Cabinet Flush Surround |
| 4210-0040 | SP1X Battery Cabinet |
| 4210-0041 | SP8X Battery Cabinet |
