EvacUElite Emergency Warning & Intercom System

The EvacUElite Emergency Warning and Intercom System features a modular, card-frame architecture housed within a self-contained cabinet providing a flexible solution for projects small and large.

The EvacUElite presents fully compliant, operator-friendly control and indication functionality via a colour touch screen user interface. A practical and operator-friendly menu layout provides time and cost-saving features during installation, operation, and maintenance.

- Easy to navigate touch screen user interface.
- Digital audio.
- Background music inputs.
- Software supports up to 512 Emergency Zones and 1024 Warden Handsets.
- Networkable up to 64 nodes.

Approvals: AS 4428.16:2020 Grade 1, AS 4428.4:2016, and AS 7240.4:2018.

Check out where EvacUElite has been recently installed:

Wenona School – Ampac
Cancer Council SA – Ampac
UnitingSA West Lakes – Ampac

First Name
Last Name
Email
Company
Job Title
Phone
State
Country

Message
I agree that by submitting this form, I accept the websites terms of use and privacy policy.
I agree to Ampac providing software updates, product updates, offers and promotions via email that may be of interest to me

The EvacUElite Emergency Warning and Intercom System features a modular, card-frame architecture housed within a self-contained cabinet providing a flexible solution for projects small and large.

- Easy to navigate touch screen user interface.
- Digital audio.
- Background music inputs.
- Software supports up to 512 Emergency Zones and 1024 Warden Handsets.
- Networkable up to 64 nodes.

Approvals: AS 4428.16:2020 Grade 1, AS 4428.4:2016, and AS 7240.4:2018.

Check out where EvacUElite has been recently installed:

Wenona School – Ampac
Cancer Council SA – Ampac
UnitingSA West Lakes – Ampac

Downloads Specifications Add Ons

Product Data Sheet

Installation & Commissioning Manual

Consultant Specification

LPCB Certificate

ActivFire Certificate

Dimensions	13U Wall Mount Enclosure – H 900 x W 650 x D 380 mm
Dimensions	24U Floor Standing Enclosure – H 1800 x W 650 x D 380mm
External Operating Voltage (240 V AC)	204 – 264 V AC
Max No. of Emergency Zones	512
Max No. of Warden Handsets	1024
Max No. of Nodes	64
Amplifier Sizes	Dual 25 Watt, 50 Watt, 150 Watt (4 Way Splitter)
Output to Warning Devices (Visual) Contacts Rated at 2 Amps Max Current Draw 6 Amps	2 Wire Single End O/Ps 8 x 750 mA OR Reverse Polarity Options
Graphical User Interfaces	13U = 3 / 24U = 7
Universal Rack Frames	13U = 2 / 24U = 5
Networking Specifications (Node to Node)	2 Core 0.75mm² Copper Twisted and Screened Cable <750m between nodes Cat5e /6 up to 100m Single Mode Fibre Multi-Mode Fibre See installation manual for details
Power Supply	13U = Max 2.4KWatt / 24U = Max 3.6KWatt
Max Battery Size (Pair)	13U = 100 AmpHr / 24U = 190AmpHr
Mains Current (Max)	13U = 13 Amps fitted with 25 Amp Breaker / 24U = 19.5Amps fitted with 25 Amp Breaker
